collection mcmaster, vendor ti, year 1978, foundry unknown, tech unknown

Datasheet: “TMS 5200 VOICE SYNTHESIS PROCESSOR”

Package

Label (top):

Die

Size: 6166 x 5121 um

Text:

T0285E
2501E

(C)
1978

NOTE: the (C) 1978 was in metal and is etched off, its barely visible in the pad areas above the lower right ROM

Map

Top metal: https://siliconpr0n.org/map/ti/tms5200nl/mcmaster_mz_mit20x/
