collection mcmaster, vendor sony, type unknown, year unknown, foundry unknown

Package

Die

Single (15711×14122, 76.2777MiB)

collection digshadow, vendor sony, year unknown, tech unknown, foundry unknown

Datasheet: unknown

Package

Label (top):

Sony Computer
Entertainment
Inc. (C) E35D
424688. 185
SSBZ9540C

Die

Tex:

MC68HC05L16
(C) 1996 (M)
E35D
MOTOROLA , INC.

Map

Top metal @ Mit20x: http://siliconpr0n.org/map_fixme/motorola_sony_ssbz9540c/mz_mit20x/

Unstitched source images: http://siliconpr0n.org/map_fixme/motorola_sony_ssbz9540c/mz_mit20x_raw/
Single (15711×14122, 79.98MB): http://siliconpr0n.org/map_fixme/motorola_sony_ssbz9540c/single/motorola_sony_ssbz9540c_mz_mit20x.jpg
Focus seems a bit off
