struers:start
Table of Contents
Country: Denmark
“In 1988 the company Logitech, in Glasgow, Scotland, is taken over.”
- No mention of Struers on logitech.uk.com history page. Coincidence / unrelated?
- “Logitech was founded in 1965. The company was developed from a research project into advanced semiconductor materials at the University of Glasgow.”
Lapping machines
| Image | Model | Description | Platen | Platen diameter | Power | Size class | Polish method | Manual | Notes |
|---|---|---|---|---|---|---|---|---|---|
  [eBay furexph 181493240930] | 15163100 | Tabletop | |||||||
| AbraPlan-20 | |||||||||
| AbraPol-20 | |||||||||
  [eBay bid-servicellc 251612196399] | Abramin | Tabletop | “150/300 rpm, specimen holder motor 180 rpm…Variable force applied to specimens from 30 to 450…10 in. dia. wheel.” | ||||||
 With (Pedimen-S?) [eBay markvlab 271623668516] | DAP-2 | Tabletop | |||||||
| DAP-6 | 1x 250 mm | Tabletop | Yes | 250 rpm | |||||
| DAP-7 | 1x 250 mm | Tabletop | Yes | 125/250 rpm | |||||
| DAP-8 | 1x 250 mm | Tabletop | Yes | 300/600 rpm | |||||
| DAP-V | 1x 250 mm | Tabletop | Yes | 40-600 rpm (stepless) JM has one bought as sort of an impulse buy. I have never used it |
|||||
| Hexamatic | |||||||||
 [LaboPol brochure] | LaboPol-1 | Tabletop | Simple platen Parallel arm option | single speed machine, 250 rpm | |||||
| LaboPol-2 | Tabletop | Simple platen Parallel arm option | two speed machine, 250 and 500 rpm | ||||||
| LaboPol-4 | Tabletop | Simple platen Parallel arm option | variable speed, 12-120 rpm | ||||||
  [eBay bishop9634 251578468244] | LaboPol-5 | Tabletop | Simple platen Parallel arm option | variable speed, 50-500 rpm | |||||
| LaboPol-6 | Tabletop | Simple platen Parallel arm option | variable speed, 120-1200 rpm | ||||||
| LaboPol-21 | Tabletop | Simple platen Parallel arm option | two discs, single speed, 250 rpm | ||||||
 [LaboPol brochure] | LaboPol-25 | Tabletop | Simple platen Parallel arm option | two discs, variable speed, 50-500 rpm | |||||
 [LaboPol brochure] | LaboPol-35 | Tabletop | Simple platen Parallel arm option | variable speed, 50-500 rpm | |||||
 With Pedemax-2 [eBay hi-techstuff 180963732684]  Above: [ebay:hgrindustrialsrpls:261466607008] | Planopol-2 | ||||||||
  [eBay bamko1 301188976608] | Planopol V | 4010188? | |||||||
 [eBay nc_inspection 281462609977] With Pedemat  [eBay frankbacon 221470525925] | Rotopol-1 | ||||||||
 [eBay nc_inspection 291262910908] | Rotopol-2 | ||||||||
 [ebay buyhitek 360528561461] | Rotopol 21 | ||||||||
| RotoPol-22 | |||||||||
  With RotoForce-4 [eBay bigboots482011 221556858585] | RotoPol-25 | ||||||||
| STELLAPOL | |||||||||
 [eBay mr-keyboard 191211383348] | TegraPol-15 | looks like a nice unit with LCD, serial port, pump etc Hot cell option |
|||||||
| Tegramin |
Lapping accessories
| Image | Model | Description | For polisher | Notes |
|---|---|---|---|---|
 [LaboPol brochure] | LaboForce-1 | Parallel arm | LaboPol series | speed of 8 rpm |
 [LaboPol brochure] | LaboForce-3 | Parallel arm | LaboPol series | speed of 250 rpm |
 With LaboPol-35 [LaboPol brochure] | LaboForce-Mi | Parallel arm | LaboPol-35 | speed of 4 rpm |
| LaboDoser | Slurry dispenser | Generic? | “Dosing unit for LaboPol with LaboForce. With built-in timer and 4 peristaltic pumps for dosing of diamond suspension, lubricant and all-in-one products such as DiaPro and DiaDuo.” | |
 With RoboCom [eBay mckean2002 221522388970] | Multidoser | Slurry feed | Generic? | Lapping compound mixer |
  [eBay surplustechmart 81218215254] | MOVIPOL | Controller? | Polish and etch controller | |
| With Planopol-2 [eBay hi-techstuff 180963732684] | Pedemax-2 | Parallel arm | Planopol-2, Planopol-V | 2762445? |
| Pedemin | Parallel arm | DAP-6 DAP-7 DAP-8 DAP-V | ||
  With Rotopol-1 [eBay frankbacon 221470525925] | Pedemat | Parallel arm | ||
| With DAP-2 [eBay markvlab 271623668516] | (Pedimen-S?) | Parallel arm | ||
| With Multidoser [eBay mckean2002 221522388970] | RoboCom | Controller | ||
| RotoForce-3 | Parallel arm | |||
| With RotoPol-25 [eBay bigboots482011 221556858585] | RotoForce-4 | Parallel arm | ||
| StruersLAN | Controller | |||
 [LaboPol brochure] | SystemAble | Jig | LaboPol series? | For thinning specimins |
| TegraDoser-1 | Slurry dispenser | 1 bottle | ||
| TegraDoser-5 | Slurry dispenser | 7 bottles | ||
| TegraForce-1 | Parallel arm | TegraPol-11 TegraPol-15 | 10-50 N | |
| TegraForce-3 | Parallel arm | TegraPol-21 TegraPol-25 TegraPol-31 TegraPol-35 | 30-400 N | |
| TegraForce-5 | Parallel arm | TegraPol-21 TegraPol-25 TegraPol-31 TegraPol-35 | 10-100 N, 30-400 N |
TegraSystem
See [TegraSystem] for equipment compatibility
Has some nice features like slurry cartridges remembering the equipment settings
